Опис
• Adapters support up to a 4K video resolution, so meeting attendees will be able to see the displayed content for improved comprehension and detailed decision making.
• Adapters are colour coded, so no more frustration trying to find the adapter that you typically use for your laptop.
• Integrated pull tab, so the adapters can be accessed quickly or easily reached when they are tucked away.
• Installation tools are included, so you save time and money by not needing to purchase any additional tools.
• USB Type-C to HDMI Adapter: 100% Functional Test at 4K/60Hz/4:4:4 Resolution with Standard AV Test Equipment
• DisplayPort to HDMI Adapter: 100% Functional Test at 4K/30Hz Resolution with Standard AV Test Equipment
• Mini DisplayPort to HDMI Adapter: 100% Functional Test at 4K/30Hz Resolution with Standard AV Test Equipment
Electrical Specifications
• USB Type-C to HDMI Adapter Power Consumption: 1050mW (210mA/5.0V)
• DisplayPort to HDMI Adapter Power Consumption: 396mW (120mA/3.3V)
• Mini DisplayPort to HDMI Adapter Power Consumption: 396mW (120mA/3.3V)
Physical Specifications
• Operating Temperature: 0°C – 40°C (0% – 90%RH)
• Storage Temperature: -10°C – 60°C (0% – 90%RH)
Physical Characteristics
• HDMI 19pin Female Connector: Solder Type, Contacts: Brass, Gold Flash, Housing: LCP, Black, Shell: Nickel Plated
• USB Type-C Male Connector: Solder Type, Contacts: Brass, Gold Flash, Housing: LCP, Black, Shell: Nickel Plated
• DisplayPort Male Connector: Solder Type, Contacts: Brass, Gold Flash, Housing: LCP Black, Shell: Nickel Plated
• Mini DisplayPort Male Connector: Solder Type, Contacts: Brass, Gold Flash, Housing: LCP Black, Shell: Nickel Plated
• Adapter Hood: Molded Black (Pantone/#Black 6C) PVC
• USB Type-C to HDMI Adapter Colour Band: Green (Pantone#354C) 12 x 1.5mm
• DisplayPort to HDMI Adapter Colour Band: Red (Pantone#032C) 12 x 1.5mm
• Mini DisplayPort to HDMI Adapter Colour Band: Yellow (Pantone#012C) 12 x 1.5mm
• Black Metal Screws (x2): 4.8 x 17.1mm, M3, Material: Steel
• Locking Coupler (x2): ø6.0 x 5mm, M3, Material: Brass, Colour: Black
• Nut (x2): ø4.5 x 3.8mm, M3, Material: Brass, Colour: Black
• Pull Tab: 80 x 25 x 2mm, Material: Polyester, Black Background, White Text, with Black Eyelet
• Hex Nut Tool: Material: Steel, 17 x 47 x 1.5mm
• Steel Wire: OD 1.2mm, Colour: Black
• Cable Stopper: 58 x 98mm, Molded Black (Pantone/#Black 6C) 30P PVC
• Product is CE marked and conforms to 2011/65/EU ROHS 2
