Опис
• Supports all USB 3.1 (Gen2) including data transfer rate up to 10Gbps
• Backwards compatible with USB 3.0, 2.0, and 1.1
• Supports all Alt mode features outputting full DisplayPort including multi-streaming
• Deliver up to 100watts of power to or from a connected source
• Gold flashed laser welded contacts
• USB-IF Certified
• USB Specification: USB 3.1 (Gen 2)
• Pair Attenuation: ≥ -1.02dB at 50MHz, -1.43 dB at 100MHz, -2.40 dB at 200MHz, -4.35 dB at 400MHz
• Pair Differential Impedance: 75 – 105Ω
• Propagation Delay: 20ns max
• Skew: 100ps max
• Fitted Insertion Loss (ILfitatNq): ≥ -4dB at 2.5GHz, -6dB at 5GHz, -11dB at 10GHz
• Voltage Drop: 250mV for GND and 500mV VBUS
• Conductor Resistance: 378Ω/km at 20°C Max 30AWG
• Insulation Resistance: 10m-km min at 20°C DC 500V (EIA-364-21)
• Dielectric Strength: AC 500V/1 minute no breakdown (EIA-364-20)
Physical Specifications
• Operating temperature: 0° – 50°C; 15-85% RH (Non-condensing)
• Storage temperature: -25° – 70°C; 15-85% RH (Non-condensing)
• Conductor 4 Pair: 30AWG (7/0.10 Bare Copper) Drain (19/0.06 Tinned Copper) Shield (Aluminium Foil+Mylar)
• Conductor 1 Pair: 32AWG (7/0.08 Bare Copper) Drain (7/0.08 Tinned Copper) Shield (Aluminium Foil+Mylar)
• Conductor 2 Conductors: 26AWG (19/0.1 Bare Copper)
• Conductor 4 Conductors: 34AWG (7/0.06 Bare Copper)
• Inner Jacket Shield: Braid (16/11/0.08 Tinned Copper)
• Jacket: 5.2±0.15mm Black
• Approvals: CE, RoHS2, USB-IF
• Housing materials: Plastic
• Housing dimensions (LxWxH): 27±.01 x 6.5 x 6.4±.01mm
• Cable length: 1000mm ± 20mm
• Connector: USB-C Male 3.1 (Gen 2) Contacts (Gold Flashed) Shell (Nickel Plated)
• Weight: 0.121 lbs (54.88 g)
